Applications

Get Apps (View-All)

GET

{{baseUrl}}/orchestrator/api/apps/?org_id=

Returns all applications of the user if no org_id is specified.

Returns applications, which belong to the given org_id if provided.

Click to see the details

Query Parameters

Name

Type

Description

Example

org_id

number

Returns apps, which groups belong to the specified organization ID.

If org_id is not specified, returns all apps of the user.

7b0ba117-e690-4651-a337-810beb51b420

Response (Success)

JSON
HTTP/1.1 200 OK

Returns all apps of the user if no org_id is specified. Returns all apps, which belong to the given org_id if provided.

Example

JSON
[
    {
        "id": "bfd25f79-4e9f-4eaf-9c4e-6d277cc523b8",
        "version": "0.0.1",
        "component_id": "7b3505d9-2909-4178-b5e4-894314dac051.banking2_flow_DEVAws_NEW.Apps.orc.ocp-qa-dev",
        "schema_version": 1,
        "description": null,
        "labels": [],
        "displayed_name": "banking2_flow_DEVAws_NEW [ocp-qa-dev]",
        "created_at": "2024-11-13T09:24:40.849999Z",
        "updated_at": "2024-11-13T09:24:40.850016Z",
        "deployed_at": null,
        "production_flowapp_id": "4981c99e-6c51-4bd6-9b68-d3c09791d754.PRD_banking2_flow_DEVAws_NEW.Flow.ocp-qa-dev@PRD_banking2_flow_DEVAws_NEW.ocp-qa-dev",
        "sandbox_flowapp_id": "4981c99e-6c51-4bd6-9b68-d3c09791d754.SND_banking2_flow_DEVAws_NEW.Flow.ocp-qa-dev@SND_banking2_flow_DEVAws_NEW.ocp-qa-dev",
        "input_fields": [
            "31"
        ],
        "output_fields": [
            "1"
        ],
        "reportable": true,
        "reporting_type": "SelfService",
        "user_id": "7b3505d9-2909-4178-b5e4-894314dac051",
        "group": "ocp-qa-dev",
        "name": "banking2_flow_DEVAws_NEW",
        "from_snapshot_version": "",
        "shared_with": [],
        "application_type": "ocp",
        "canvas": "80c17f68-f222-4212-985a-fae2136bdf15",
        "from_snapshot": null
    },
...
]

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Get Apps (Paginated)

GET

{{baseUrl}}/orchestrator/api/apps/pagination/?limit=X&offset=Y?org_id=

Returns all applications of the user as paginated content if no org_id is specified.

Returns only applications, which belong to the given org_id, as paginated content.

Click to see the details

Query Parameters

Name

Type

Description

Example

limit

number

Limits the number of applications to return.

3

offset

number

Sets the sequence number from the beginning, from which the apps should be returned.

4

org_id

number

Returns only apps, which groups belong to the specified organization ID.

If org_id is not specified, returns all apps of the user.

7b0ba117-e690-4651-a337-810beb51b420


Response (Success)

JSON
HTTP/1.1 200 OK

Returns all apps within the set limit, offset, and org_id.

Example

JSON
{
    "count": 8,
    "results": [...]
}

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Get App

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/

Returns the App by app_id.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The application id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the App.

Example

JSON
{
    "name": "my_app",
    "canvas_id": "8101c262-be18-40c7-a85a-78b47dcdf80d"
}

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Get App Status

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/status/

Gets the status of the App.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Example

JSON
{
    "status": "started/stopped/not-deployed"
}

Parameter

Type

Description

status

string

The application status.

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Get App MiniApps

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/miniapps/?detail=&type=

Get the list of miniApps used by this application, including all of its flows.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Query Parameters

Name

Type

Description

Example

detail

boolean

Applicable if extra details about the miniApps should be included. False by default.

true

type

string

miniApp type used as filter.

"Banking", "Numeric", "Intent"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns a list of miniApp ids by default. More details can be returned with the detail query parameter.

Example 1

{{baseUrl}}/orchestrator/api/apps/<app_id>/miniapps/

JSON
[
    "b759a24f-6afa-4bcf-b213-257ee6037175.ia_orc_intent.Banking.MiniApps.orc",
    "b759a24f-6afa-4bcf-b213-257ee6037175.ia_orc_announcement_2.Announcement.MiniApps.orc",
    "4d5195f9-ce70-488c-bb3c-f67bc567521f.dt_orc_ann_info_yes.Announcement.MiniApps.orc"
]

Example 2

{{baseUrl}}/orchestrator/api/apps/<app_id>/miniapps/?detail=true

JSON
[
    {
      "id": "b759a24f-6afa-4bcf-b213-257ee6037175.ia_orc_intent.Banking.MiniApps.orc",
      "name": "ia_orc_intent",
      "type": "Banking"
    },
    {
      "id": "b759a24f-6afa-4bcf-b213-257ee6037175.ia_orc_announcement_2.Announcement.MiniApps.orc",
      "name": "ia_orc_intent",
      "type": "Announcement"
    }
]

Get App Flows

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/flows/

Get the list of Flows used by this app.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the list of Flows.

Example

JSON
[
    {
        "id": "660f41a1-75e2-4c29-bdde-a90ab529b30d",
        "version": "0.0.2",
        "component_id": "88ed36b3-4e0c-4b5b-b9be-c733b3c5f21f.orc_export_test_flow.Flows.orc.ktselepakis",
        "created_at": "2022-02-17T15:02:01.509054Z",
        "updated_at": "2022-04-15T09:31:47.631558Z",
        "production_flowapp_id": "88ed36b3-4e0c-4b5b-b9be-c733b3c5f21f.PRD_orc_export_test_flow.Flow.ktselepakis@PRD_orc_export_test_flow.ktselepakis",
        "sandbox_flowapp_id": "88ed36b3-4e0c-4b5b-b9be-c733b3c5f21f.SND_orc_export_test_flow.Flow.ktselepakis@SND_orc_export_test_flow.ktselepakis",
        "user_id": "88ed36b3-4e0c-4b5b-b9be-c733b3c5f21f",
        "group": "ktselepakis",
        "name": "orc_export_test_flow",
        "input_fields": [
            "foo"
        ],
        "output_fields": [
            "bar"
        ],
        "canvas": "a8a9791f-205c-4995-bf20-1be2e860dc4a"
    }
]

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Create App

POST

{{baseUrl}}/orchestrator/api/apps/

Creates an App.

Click to see the details

Name

Type

Description

Example

name

string

-

The application name

Example

JSON
{
    "name": "my_app"
}

Response (Success)

JSON
HTTP/1.1 201 CREATED

The created App.

Example

JSON
{
    "name": "my_app",
    "canvas_id": "8101c262-be18-40c7-a85a-78b47dcdf80d"
}

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Response (Failed)

JSON
HTTP/1.1 400 BAD_REQUEST

The failed status 400 BAD_REQUEST can be returned if the app name contains invalid characters (acceptable app name characters are only alphanumeric [a-Z0-9] and the underscore character '_').

Example

JSON
{
    "name": [
        "Invalid app name. App name must contain only alphanumeric characters and the underscore character."
    ]
}

Delete App

DELETE

{{baseUrl}}/orchestrator/api/apps/<app_id>/

Deletes the app by its app_id.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 204 NO_CONTENT

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Deploy App (Changes Only / All)

POST

{{baseUrl}}/orchestrator/api/apps/<app_id>/deploy/?all=true

Deploys the app (changes only/all).

This request compiles the Orchestrator App, creates a relative DiaManT App (if there is none), uploads a DiaManT App configuration, makes the deployment and starts the application.

Any moved node on canvas is considered a change.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Query Parameters

Name

Type

Description

Example

all

boolean

If this parameter set to true, then the application is re-deployed.

true

async

boolean

If this parameter set to true, then the asynchronous deployment is activated.

Please note that this feature is not available to all environments yet.

true

Response (Success)

JSON
HTTP/1.1 200 OK

The deployment results.

Example 1

{{baseUrl}}/orchestrator/api/apps/<app_id>/deploy/?all=true

JSON
{
    "detail": "The application has been deployed and start and running successfully."
}

Example 2

{{baseUrl}}/orchestrator/api/apps/<app_id>/deploy/

JSON
{
    "detail": "The application has been deployed and start and running successfully."
}

Example 3

Please note that asynchronous deployment is not available to all environments yet.

{{baseUrl}}/orchestrator/api/apps/<app_id>/deploy/?all=true&async=true

JSON
{
    "result_id": "392ad79d-c43a-4bb4-bfa9-0874335e65ee"
}

Response (Failed)

JSON
HTTP/1.1 400 BAD_REQUEST

The failed status 400 BAD_REQUEST can be returned if something went wrong with the app deployment. Usually, there was a canvas warning.

Example

JSON
{
    "detail": "Your App can not be deployed because it contains problems: Multiple roots found on the graph.",
    "errors": [
        {
            "canvas_id": "1ebbcc51-19a2-47cb-bba9-0bc6164a94cb",
            "node_errors": [
                {
                    "node_id": "1",
                    "errors": [
                        {
                            "type": "WARNING",
                            "code": "MULTIPLE_ROOTS_FOUND",
                            "message": "Multiple roots found on the graph.",
                        }
                    ]
                },
                {
                    "node_id": "2",
                    "errors": [
                        {
                            "type": "WARNING",
                            "code": "MULTIPLE_ROOTS_FOUND",
                            "message": "Multiple roots found on the graph.",
                        }
                    ]
                }
            ]
        }
    ]
}

Deploy Legacy Application

POST

{{baseUrl}}/orchestrator/api/apps/{{app_id}}/deploy_legacy/?async=true

Deploys a legacy application

A legacy Application is an older application that was created before OCP. It is a group of manually made and zipped DiaManT XML files that are sent directly to DiaManT without any checks or processing by Orchestrator.

The purpose of deploying legacy Applications is to bring previously developed Applications into the OCP system. Additionally, when a user creates a legacy type Application in Orchestrator, a DiaManT App is generated, and deploying a legacy App involves changing its configuration.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b499774-3a0a-60c1-8a1c-4a124170v6f3"

Query Parameters

Name

Type

Description

Example

all

boolean

If this parameter set to true, then the application is re-deployed.

true

async

boolean

If this parameter set to true, then the asynchronous deployment is activated.

Please note that this feature is not available to all environments yet.

true

Response (Success)

JSON
HTTP/1.1 200 OK

The deployment results.

Example

Please note that asynchronous deployment is not available to all environments yet.

{{baseUrl}}/orchestrator/api/apps/<app_id>/deploy_legacy/?async=true

JSON
{
    "result_id": "392ad79d-c43a-4bb4-bfa9-0874335e65ee"
}

Response (Failed)

JSON
HTTP/1.1 400 BAD_REQUEST

The failed status 400 BAD_REQUEST can be returned if something went wrong with the app deployment. Usually, there was a canvas warning.

Example

JSON
{
    "detail": "Your App can not be deployed because it contains problems: Multiple roots found on the graph.",
    "errors": [
        {
            "canvas_id": "1ebbcc51-19a2-47cb-bba9-0bc6164a94cb",
            "node_errors": [
                {
                    "node_id": "1",
                    "errors": [
                        {
                            "type": "WARNING",
                            "code": "MULTIPLE_ROOTS_FOUND",
                            "message": "Multiple roots found on the graph.",
                        }
                    ]
                },
                {
                    "node_id": "2",
                    "errors": [
                        {
                            "type": "WARNING",
                            "code": "MULTIPLE_ROOTS_FOUND",
                            "message": "Multiple roots found on the graph.",
                        }
                    ]
                }
            ]
        }
    ]
}

Get Async Deployment Status

GET

{{baseUrl}}/orchestrator/api/results/<result_id>/

Returns the status of asynchronous deployment by result_id.

Please note that this feature is not available to all environments yet.

Click to see the details

URL Parameters

Name

Type

Description

Example

result_id

uuid

The result id.

"7b7382bc-be7b-4b2f-829c-825a93ebac3c"

The result_id can be retrieved from . The results of the asynchronous deployment are saved for 24 hours and can be retrieved within this time.

Response (Success)

JSON
HTTP/1.1 200 OK

The deployment results.

Example

{{baseUrl}}/orchestrator/api/results/<result_id>/

JSON
{
    "task_id": "392ad79d-c43a-4bb4-bfa9-0874335e65ee",
    "async_result": "App ek_local_uswest_1 has been deployed successfully."
}

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Example

JSON
{
    "detail": "Task result 7b7382bc-be7b-4b2f-829c-825a93ebac3c not found."
}

Get Web Chat Info

Help start a chat simulation with an App by providing useful web chat related info.

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/web_chat/

Helps start a chat simulation with an app by providing useful web chat related info.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns web-chat related info.

Parameter

Type

Description

chat_url

string

The URL linked to the chat connector web socket.

deployed_token

string

The access token for the deployed application.

live_token

string

The access token for the simulator application.

Example

JSON
{
    "chat_url": "wss://lab.miniapps.ocp.ai/chat/ws/dialogs",
    "deployed_token": "435f6ea2f72df13732c29414a0446a9e11d7fd46412bfe1c3fc1961736d8ff71467623cb64532352",
    "live_token": "1c58b47ae31fb9e8a8b89b4e201f821d3ac5983492619fe8f740dd2404010c6134673c6869fe64ae"
}

Get App's Attached Data

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/attached_data/

Gets the application's attached data.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the app's attached data (key/value pairs).

Example

JSON
{
    "ad_key_1": "ad_value_1",
    "ad_key_2": "ad_value_2",
    "ad_key_3": "ad_value_3"
}

Update App's Attached Data

PUT

{{baseUrl}}/orchestrator/api/apps/<app_id>/attached_data/

Updates the application's attached data.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the updated app's attached data (key/value pairs).

Example

JSON
{
    "ad_key_1": "ad_value_1",
    "ad_key_2": "ad_value_2",
    "ad_key_3": "ad_value_3"
}

Get App's Fail Sources

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/fail_sources/

Returns the App's list of Fail Sources that can be used as fail sources for Error Handlers.

Click to see the details

Fail Sources contain a display_name and a fail_source_path:

  • display_name is more user-friendly and is meant for users to read;

  • fail_source_path is the actual value that needs to be used when setting an ErrorSource for an Error.

URL Parameters

Name

Type

Description

Example

app_id

uuid

the app's id

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the list of App's fail sources.

Parameter

Type

Description

Example

display_name

string

Fail source's name to display.

"ia_iandronis_intent_1"

fail_source_path

string

Fail source's path.

"0e694182-1cec-406d-83ce-46cdf9d56b1c.ia_iandronis_intent_1.Banking.MiniApps.iandronis"

Example

JSON
[
  {
    "display_name": "ia_iandronis_intent_1",
    "fail_source_path": "0e694182-1cec-406d-83ce-46cdf9d56b1c.ia_iandronis_intent_1.Banking.MiniApps.iandronis"
  },
  {
    "display_name": "ia_iandronis_announcement_1",
    "fail_source_path": "0e694182-1cec-406d-83ce-46cdf9d56b1c.ia_iandronis_announcement_1.Announcement.MiniApps.iandronis"
  },
  {
    "display_name": "ia_local_lab_flow_1.ia_iandronis_intent_1",
    "fail_source_path": "0e694182-1cec-406d-83ce-46cdf9d56b1c.ia_local_lab_flow_1.Flows.orc.iandronis::0e694182-1cec-406d-83ce-46cdf9d56b1c.ia_iandronis_intent_1.Banking.MiniApps.iandronis"
  },
  {
    "display_name": "ia_local_lab_flow_1.ia_iandronis_announcement_2",
    "fail_source_path": "0e694182-1cec-406d-83ce-46cdf9d56b1c.ia_local_lab_flow_1.Flows.orc.iandronis::0e694182-1cec-406d-83ce-46cdf9d56b1c.ia_iandronis_announcement_2.Announcement.MiniApps.iandronis"
  }
]

Response (Failed)

JSON
HTTP/1.1 400 BAD_REQUEST

The failed status 400 BAD_REQUEST can be returned if there was a cycle reference inside the app (probably by some flows).

Example

JSON
{
  "detail": "Found cycle use of a Flow in the application (use trace: ['test_user_id.my_app.Flows.orc.group', 'test_user_id.my_flow_lvl_1.Flows.orc.group', 'test_user_id.my_flow_lvl_2.Flows.orc.group'] -> test_user_id.my_flow_lvl_1.Flows.orc.group)."
}

Get App's Export

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/export/

Exports the application and all the related flows in a ZIP file.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the app's export file.

Response (Failed)

JSON
HTTP/1.1 404 NOT_FOUND

Get Available Voice Biometric (VB) Profiles

GET

{{baseUrl}}/orchestrator/api/voice-biometric/profiles/

Gets the available Voice Biometric (VB) Profiles.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the list of Voice Biometric Profiles.

Example

JSON
[
    {
        "profile_id": "DEF",
        "name": "Default",
        "bio_keys": [
            {
                "id": 1,
                "key": "userID",
                "display_name": "userID"
            },
            {
                "id": 168,
                "key": "Ani",
                "display_name": "Ani"
            }
        ]
    },
    {
        "profile_id": "XLh0g6d0",
        "name": "test",
        "bio_keys": [
            {
                "id": 276,
                "key": "user_id",
                "display_name": "user_id"
            },
            {
                "id": 277,
                "key": "Ani",
                "display_name": "Ani"
            }
        ]
    }
]

Get App's Voice Biometric Profile

GET

{{baseUrl}}/orchestrator/api/apps/<app_id>/voice-biometric/

Gets the App's Voice Biometric Profile.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the App Biometric Profile.

Example

JSON
{
    "profile_id": "DEF",
    "field_mappings": [
        {
          "bio_key": "Ani",
          "orc_field": "Ani"
        },
        {
          "bio_key": "userID",
          "orc_field": "Dnis"
        }
    ]
}

Update App's Voice Biometric Profile

PUT

{{baseUrl}}/orchestrator/api/apps/<app_id>/voice-biometric/

Updates the App's Voice Biometric Profile.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Request payload

The App Voice Biometric Profile variables.

Response (Success)

JSON
HTTP/1.1 200 OK

Returns the updated App Voice Biometric Profile.

Example

JSON
{
    "profile_id": "DEF",
    "field_mappings": [
        {
          "bio_key": "Ani",
          "orc_field": "Ani"
        },
        {
          "bio_key": "userID",
          "orc_field": "Dnis"
        }
    ]
}

Unset App's Voice Biometric Profile

PUT

{{baseUrl}}/orchestrator/api/apps/<app_id>/voice-biometric/

Sends update request with empty profile_id value to remove the connection between VB profile keys and Orchestrator fields.

Click to see the details

URL Parameters

Name

Type

Description

Example

app_id

uuid

The app's id.

"9b399774-3a0a-40c1-8a1c-4a124170b6f3"

Request payload

The app Voice Biometric Profile variables.

Response (Success)

JSON
HTTP/1.1 200 OK

The updated App Voice Biometric Profile.

Example

JSON
{
    "profile_id": "",
    "field_mappings": []
}

Models

Voice Biometric Profile

Click to see the details

Name

Type

Description

profile_id

string

The profile's id.

name

string

The profile's name.

bio_keys

array[dict]

The profile's bio keys.

Example

JSON
{
    "profile_id": "DEF",
    "name": "Default",
    "bio_keys": [
        {
            "id": 1,
            "key": "userID",
            "display_name": "userID"
        },
        {
            "id": 168,
            "key": "Ani",
            "display_name": "Ani"
        }
    ]
}

App Voice Biometric Profile

Click to see the details

Name

Type

Description

profile_id

string

The Voice Biometrics profile's id.

field_mappings

array[dict]

Mapping of Orchestrator Application field (key) to Voice Biometrics bio_key id (value).

Example

JSON
{
    "profile_id": "DEF",
    "field_mappings": [
        {
          "bio_key": "Ani",
          "orc_field": "Ani"
        },
        {
          "bio_key": "userID",
          "orc_field": "Dnis"
        }
    ]
}
JavaScript errors detected

Please note, these errors can depend on your browser setup.

If this problem persists, please contact our support.
